Streamer Wi-Fi WiiM mini, 24bit /192kHz, Bluetooth 5.2, AUX, SPDIF, Spotify si Tidal Connect, Airplay 2

Descriere





Audio Codec
MP3, AAC, ALAC, APE, FLAC, WAV, WMA, OGG

---

Wireless Network
IEEE 802.11 b/g/n/ac dual band Wi-Fi 5

---

Bluetooth
Bluetooth 5.2

---

Line in
1Vrms

---

Line out
Line in to Line out：
Power Output=2Vrms
THD+N Ratio=0.009%
SNR=102dB
Crosstalk=-106dB
Dynamic Range=96dB
BT in to Line out：
Power Output=2Vrms
THD+N Ratio=0.009%
SNR=102dB
Crosstalk=-106dB
Dynamic Range=96dB

---

SPDIF
Line in to SPDIF out：
Power Output=-3dBFS
THD+N Ratio=0.005%
SNR=102dB
Crosstalk=-103dB
Dynamic Range=97dB
BT in to SPDIF out：
Power Output=0dBFS
THD+N Ratio=0.005%
SNR=297dB
Crosstalk=-364dB
Dynamic Range=213dB

---

Power Supply
5V,1A

---

LED
Three color status LED - Red, Green and White.

WiiM Mini LED Behaviors >

---

Button
Capacitive touch - Play/Pause, Volume+, Volume-
